The VIBSOL mount is a simple and quick solution for machine tools offering a good shock absorption, and easy to install by sliding it under the base of the machine.
Unaffected by oils, cutting fluids, detergents, high and low temperatures with good resistance to fatigue.
It offers good stability for the suspended machine.
A constant natural frequency over a wide load range makes mount selection easy.
The VIBSOL mount is made of a round metal cushion covered with ananti-slip elastomer pad on both side.
It is available in two versions:
– a standard version with a natural frequency of 22 à 30 Hz(machine tools).
– a thick version (W) with lower stiffness and a natural frequency of 15 to 22 Hz (metal forming machines).
This range of shock absorbers consists of two steel soles and two high-strength metal springs, light alloy joint washers and a metal cushion in stainless steel wire on each spring. An external protective sheet prevents possible intrusions of materials that stiffen the shock absorber.
All steel parts are protected by a layer of paint. These elements are very easy to assemble and adapt to the needs of the equipment.
They comply with the ISO 9001-2000 standard.
Metal shock absorber, low frequency, with semi-elastic retaining divide by means of metal mesh.
The basic element of an expansion joint is the corrugated metal bellows, annularly from a longitudinally welded tube, or seamless tube, in one, two or several lamella constructions. Designed and manufactured in compliance with EJMA standards.
Steel shock absorber working in pull and compression.
– Shroud, cup, cushions, axle and screw in stainless steel 18/8
– Damper elements in stainless steel yarn 18/8
– Protection: passivated
Weight (aprox):
MV-32: 140 gr
MV-33: 275 gr
MV-36: 640 gr
